| SENSOR | 1/3" SONY Super HAD PS CCD |
| RESOLUTION | 600TVL |
| SHUTTER | 1/60 ~ 1/100,000sec |
| PROGRAMMING | OSD Programming (CCVC in-line controller available) |
| SN RATIO | >52dB (AGC Off) |
| VIDEO OUT | VBS 1.0Vp-p (75ohm load) |
| OPERATING TEMP | -50℃ ~ +50℃ |
| IP RATING | IP66 |
| POWER | 12VDC/24VAC Auto-Sensing |
| LENS | 3.5mm ~ 16mm Varifocal / F1.4 DC Auto Iris Varifocal Lens |
| EFFECTIVE PIXELS | 768(H) x 494(V) |
| TOTAL PIXELS | 811(H) x 508(V) |
| SCANNING SYSTEM | 2:1 Interlace |
| FREQUENCY | 15.734KHz(H)/59.94KHz(V) |
| SYCHRONIZATION | INT/LL Selectable 0-359° (Adjustable) |
| MINIMUM ILLUMINATION | 0.001 Lux(Color) 0.0001Lux(B/W)F1.2 Sense-upx256_50IRE |
| WDR | Wide Dynamic Range (WDR & XDR) |
| DAY & NIGHT | COLOR/BW/AUTO/EXT |
| DNR | Digital Noise Reduction OFF/LOW/MIDDLE/HIGH/USER(1~16Levels) |
| DIS | Digital Image Stabilization OFF/ON |
| AGC | Auto Gain Control OFF/ON (Max. Level Setting) |
| BLC | Back Light Compensation OFF/ON (Area Setting) |
| WHITE BALANCE | ATW1/ATW2/AWC/MANUAL |
| SENS-UP | OFF/AUTO (Selectable ~X256) |
| MOTION DETECTION | OFF/ON (4 Zones) |
| PRIVACY FUNCTION | OFF/ON (8 Zones by Polygonal Method) |
| DIGITAL ZOOM | OFF/ON (X10) |
| FLICKERLESS | OFF/ON |
| REVERSE | Horizontal/Vertical |
| SHARPNESS | OFF/ON (Level Setting) |
| OTHER FUNCTIONS | Camera ID, Detail, PIP, etc. |
| COMMUNICATIONS | CCVC (Control Camera Vial Coaxial Cable), RS485 |
| CCVC PROTOCOL | Pelco D/P, Address 0~255 |
| MOUNTING BRACKET | 3-Axis Bracket |
| SHIPPING WEIGHT | 2.6lb (1.2kg) |
