VPR-37X-TI

The Viper (equipped with 13mm thermal lens)

The Viper The VPR-37X-TI is an integrated dual-sensor system that boasts a 37X ultra-high resolution color CCD and a highly tuned thermal imager for true 24/7 performance. Integrating these two sensors provides unparalleled performance resulting in accurate detection, recognition, and identification of intruders. All of this is integrated into a rugged IP 66 housing constructed of strengthened aluminum alloy. This internal heater/blower and wiper allows the Viper to withstand the harshest climates and the most brutal assaults, making it ideal for perimeter security, homeland defense, and coastal protection.

SENSOR1/4" Ex-View HAD II CCD
RESOLUTION600TVL (day) / 700TVL (night)
SHUTTERAuto: 1/50 - 1/10,000 Sec
PROGRAMMINGOSD
OPERATING TEMP-45°C to +60°C
IP RATINGIP 66 Nema 4X
POWER12VDC or 24VAC
THERMAL SENSORFPA, uncooled vanadium oxide micro-bolometer (cooled core available)
LENS9mm, 13mm, 19mm, 35mm, 50mm, 100mm, and 150mm
PICTURE ELEMENTS324(H) x 256(V) (optional 640x480 with 8X zoom)
SCENE TEMPERATURE -40°C to +160°C (high and low gain)
PIXEL PITCH17µm (32% sharper image over 25µm sensors) FLIR's proprietary noise reduction
IMAGE OPTIMIZATIONSBPR, NUC, & AGC'd user configurability via SDK, GUI
DIGITAL ZOOM2X & 4X dynamic zoom/pan with dyanamic range switching
THERMAL SENSITIVITY/RESPONSE36 mk @ f1.0 / 85mk @ f1.6 | 7.5-14 micron
COMMUNICATION (THERMAL CAMERA)Network or USB
IMAGE DISPLAY MODESWhite hot, black hot, false color, and color & monochrome palettes (LUTs)

Customizable Options

Germanium Lens

  • 9mm lens
  • 13mm Lens
  • 19mm Lens
  • 25mm Lens
  • 35mm Lens
  • 50m Lens
  • 60mm Lens
  • 100mm Lens
  • 21-100mm Zoom Lens
