SIGMA-3KM-1000-100TI

Long Range Dual Sensor Thermal & Active IR Day Night PTZ Camera with 500mm or 1000mm Lens

The Sigma Series by Ascendent is designed by Ascendent specifically for border, coast, pipeline and perimeter protection. This multi-sensor camera system offers a radical approach and significant advantages over conventional camera systems. Boasting both thermal and optical imagers with ZLID illumination delivers long range recognition and identification in virtually any environment. This includes heavy fog and complete darkness. The wide-angle thermal imager detects threats to provide unparalleled situational awareness to properly assess potential hazards, and threats at great distances. The high-resolution optical camera provides superior detail over thermal imaging to identify threats even in complete darkness with the aid of the ZLID laser illuminator.

SENSOR1/2" EXS CCD (IR Enhancing)
RESOLUTION540TVL Color / 600TVL B/W
SHUTTER1/100,000sec Auto Shutter
VIDEO OUTAnalog or Optional IP
ILLUMINATIONZLID 3000M
OPERATING TEMP-40ºC ~ 60ºC
IP RATINGIP66-IP68 Nema 4X
POWER12VDC/24VAC Auto-Sensing
CONSTRUCTIONRugged, weatherized treated alluimuim
FINISHReflective anti-corrosive
WEIGHT38KG (DOM)
VIDEO MODE Color by Day, Monochrome at night
PAN AZIMUTH360° endless rotation
SPEED CONTROL Closed loop (variable to zoom)
RESOLUTION ACCURACY >0.1° (closed loop)
OPERATING TEMPERATURE-45°C to +55°C (thermostatically regulated)
OPTICS46-1010mm IR corrected zoom
COMMUNICATIONPelco D/P Extended (others optional)
THERMAL IMAGERUncooled VOX FPA
THERMAL LENS100mm Geranium
HUMAN DETECTION2.4km | 7,875 Feet
VEHICLE DETECTION5.3km | 17,390
THERMAL INFRARED WAVELENGTH7.5 - 13.5μm
SENSITIVITY (NETD)<50 mK at f/1.0
THERMAL IMAGE OPTIMIZATION (TIO) BPR, NUC, & AGC’d video
DIGITAL DETAIL ENHANCEMENTYes
THERMAL MODES White hot, black hot, false color
